FMB110 small and professional tracker with internal high gain GSM and GNSS antennas, which is able to collect device coordinates and other useful data and transfer them via GSM network to server. This device is perfectly suitable for applications where location acquirement of remote objects is needed: fleet management, car rental companies, taxi companies, public transport, logistics companies, personal cars and so on. FMB110 can perform tasks on remote objects, such as monitoring engine status, controlling truck’s door etc.

GSM/GPRS core

Quad band 2G
850/900/1800/1900 MHz
Internet (TCP/UDP/HTTP/SMTP)

GPS Core

Multi channel GNSS

(GPS/Galileo/GLONASS/BeiDou) receiver
AGPS (online/offline/autonomous)
Protocols: NMEA, Falcom (binary)
Accuracy:
- Position: 2.5 m (GPS) / 4,0 m (GLONASS)
Acquisition:
- Cold Start: 29 s (GPS) / 30 s (GLONASS)
- Tracking: -161 dBm (GPS) / -158 dBm (GLONASS)
Sensitivity:
- Cold starts: -148 dBm (GPS) / -145 dBm (GLONASS)
Limits:
- Velocity: 500 m/s (972 knots)
- Altitude: 50.000 m
- Update rate: 1 Hz

Processor core

RTC
8 MB Flash (history, firmware, configuration)

Electrical characteristics

Power: +10,8 V to +32 V DC

Physical characteristics

Dimensions (LxWxH): 105 x 83 x 28 mm
Weight: approx. 130 g

Average Power Consumption

Normal operation: 50mA @ 12V DC
Sleep mode: < 1mA @12V DC

Temperature range

Storage: -40 °C to +85 °C
Operating: -40 ° to +85 °C
GSM: -40 °C to +85 °C
Battery** discharging temp.: -20 °C to +60 °C
Battery** charging: 0 ° to +45 °C

Sensors

Internal 3-axis

acceleration/temperature

Interfaces

4 IOs
  3 x Configurable digital/analog inputs
  1 x Digital input (IGN)
2 x RS232 (1 x V.24 level, 1 x RS-232****/RS-485***)
1 x USB 2.0 interface
1 x 1-Wire interface (incl. 5V phantom power)****
1 x 10pin Mini-USB-connector (for IOBOX-MINI**)
1 x I²C interface****
1 x CAN/FMS/OBD-II***
3 x Programmable LEDs
1 x 4pin audio jack interface****

Antennas

internal and external with automatic/manual switch

Certification

CE/ E1 approved; FCC/PTCRB in preparation
